Weston on the real screen

Tunix now runs Weston, the reference Wayland compositor on its own DRM driver, with the GL renderer, working keyboard and mouse, and weston-terminal rendering JetBrains Mono on the real display.

The road there

Getting a Wayland desktop on a from-scratch kernel is mostly about discovering, one crash at a time, which Linux interfaces real software quietly depends on. The plan was deliberately ordered so each step ran on top of the previous one:

1. Shared memory — memfd_create and real MAP_SHARED semantics, which immediately uncovered a mprotect/COW interaction bug in the VM layer.
2. libwayland — needed libffi, and it turned out the real missing syscall was flock.
3. Weston headless — exposed seteuid, fallocate, and mremap.
4. A simpledrm-style /dev/dri/card0 — modesetting, dumb buffers, page-flip events, and console arbitration.
5. The real thing — Weston's DRM backend on that device.

The bugs worth remembering

Two failures stood out. The first: Weston's DRM backend passes ioctl request numbers around as unsigned long, and on the way through the syscall path the constant was sign-extended the kernel compared against a value with 32 high bits set and rejected every DRM ioctl. The fix was one mask; finding it took a day.

The second was nastier. Weston forked a child, and the child scribbled over the parent's pages. The COW machinery marked pages with PAGE_SHARED semantics where it should not have a fork bug that only manifested once a real compositor exercised shared mappings and copy-on-write in the same address space.

PRIME was not optional

The GL renderer refused to work without PRIME buffer export Mesa hands buffers between contexts as dmabuf file descriptors even when everything is in software. So Tunix got DRM_IOCTL_PRIME_HANDLE_TO_FD and friends, and the GL renderer came up.

The result is a from-scratch kernel presenting a desktop that speaks the same protocols as desktop Linux. Next stop: hardware-accelerated GL through virtio-gpu and virgl.
